Electric arc furnace and electrode lifting autocontrol system
Electric arc furnace makes use of the electric power to heat and melt the charge by the high temperature electric arc which is produced between electrode and charge. It can produce common steel, high quality carbon-steel, alloy steel, ferroalloy, stainless steel and so on. So electric arc furnace is the key equipment of steel mills, foundries and fireproof material manufactories. We use the industrial computer and fuzzy control technology to regulate the up-and-down of the electrode assembly. It has many characteristics such as high control precision, fast response, low failure rate and good dependability. Also electric arc furnace has obvious advantages: producing electric arc quickly and steadily, high power factor, saving electric power, reducing breakoff of the electrode and prolonging the furnace¡¯s service life and so on.
Superiorities:
¡óThe user can control the temperature in a flexible manner by regulating the current and voltage in smelting process, in order to satisfy smelting requirements of different materials.
¡óThe furnace has high thermal efficiency.
¡óThe user can regulate atmosphere inside the furnace. In the steelmaking process of basic arc furnace, the user can largely wipe off phosphor, sulfur, oxygen and other impurities to improve the quality of steel, so the alloy recovery rate is high and stable, the steel¡¯s chemical components can be controlled easily, and also the furnace can smelt much more varieties of steel. The furnace structure is simple and the processing line is short.
New technology applications
¡óOptimized design for the parameter selection of electric arc furnace
¡óFurnace wall and cover are cooled by water in pipes
¡óEccentric bottom tapping (EBT)
¡óCopper-steel composite conducting arms
¡óBundled large-section water-cooled cable
¡óShort network of optimized structure (energy saving type)
¡óProportional valve hydraulic system, or hoisting system by steel wire rope.
¡óTwo-level industrial computer control, including PLC basic level + process level
¡óFrequency conversion control technology, network technology, nerve cell control technology, etc.
